Thermax W8568

The Thermax W8568 is a high-efficiency greenhouse thermal curtain with 85% shading and 68% energy savings. Its woven structure provides superior light diffusion and insulation, making it ideal for commercial greenhouses requiring maximum shading and temperature stability.

SKU: Thermax W8568 Categories: ,
Get Quote Today

Description

The Thermax W8568 is specifically designed for greenhouses requiring maximum shading and energy savings. With a woven structure composed of four aluminum reflective layers and one transparent layer, it offers 85% shading, effectively blocking excessive sunlight and protecting crops from overheating.

During the day, the aluminum layers reflect and diffuse sunlight, ensuring a uniform light distribution while reducing heat buildup. This helps maintain an optimal growing environment, preventing plant stress and excessive water evaporation. At night, the curtain acts as a thermal barrier, trapping warmth inside the greenhouse to stabilize temperatures and reduce heating costs. With its high insulation efficiency, the Thermax W8568 is an ideal choice for commercial greenhouses, nurseries, and controlled growing environments where temperature regulation and energy conservation are key priorities.

Specification Table

Parameter Value
SKU Thermax W8568
Application Inside
Shading Level 85%
Light Transmittance 15%
Energy Saving 68%
Pattern 4 Aluminum + 1 Transparent
Material Polyester + Aluminum
Warranty 5 years
Strip Width 4mm
Shrinkage Rate 80°C 2hrs ≤ 1%
Standard Width 3.3m, 4.3m, 5.3m, Customizable
Flame Retardant Optional
R&D Capability OEM, ODM
Minimum Order Quantity 2000 sqm
Delivery Time 10-20 days
Payment Terms T/T, L/C
